●DIMENSIONS AND CURB MASS |
|
Overall length |
2,115 mm |
|
Overall width |
785 mm |
|
Overall height |
1,060 mm |
|
Wheelbase |
1,450 mm |
|
Ground clearance |
145 mm |
|
Seat height |
815 mm |
|
Curb mass |
210kg / 213kg(ABS) |
|
●ENGINE |
|
Type |
4-stroke, liquid-cooled, DOHC |
|
Number of cylinders |
4 |
|
Bore |
72.0 mm |
|
Stroke |
46.0 mm |
|
Displacement |
749 cm3 |
|
Maximum power |
78kW/10,000rpm |
|
Compression ratio |
12.3: 1 |
|
Fuel system |
Fuel injection |
|
Air cleaner |
Paper element |
|
Starter system |
Electric |
|
Lubrication system |
Wet sump |
|
Idle speed |
1,200 ± 100 r/min |
|
●DRIVE TRAIN |
|
Clutch |
Wet multi-plate type |
|
Transmission |
6-speed constant mesh |
|
Gearshift pattern |
1-down, 5-up |
|
Primary reduction ratio |
1.857 (78/42) |
|
Gear ratios |
Low |
2.785 (39/14) |
|
2nd |
2.052 (39/19) |
|
3rd |
1.681 (37/22) |
|
4th |
1.450 (29/20) |
|
5th |
1.304 (30/23) |
|
Top |
1.181 (26/22) |
|
Final reduction ratio |
2.470 (42/17) |
|
Drive chain |
RK525SMOZ8, 112 links |
|
●CHASSIS |
|
Front suspension |
Inverted telescopic, coil spring, oil damped |
|
Rear suspension |
Link type, coil spring, oil damped |
|
Front fork stroke |
120 mm |
|
Rear wheel travel |
135 mm |
|
Steering angle |
33ﾟ(right & left) |
|
Caster |
25ﾟ20' |
|
Trail |
104 mm |
|
Turning radius |
3.0 m |
|
Front brake |
Disk brake, twin |
|
Rear brake |
Disk brake |
|
Front tire size |
120/70ZR17M/C (58W) tubeless |
|
Rear tire size |
180/55ZR17M/C (73W) tubeless |
|
|
|
●ELECTRICAL |
|
Ignition type |
Electronic ignition (Transistorized) |
|
Ignition timing |
3ﾟB.T.D.C. at 1,200 r/min |
|
Spark plug |
NGK CR9EIA-9 or DENSO IU27D |
|
Battery |
12V 36.0 kC (10Ah)/10 HR |
|
Generator |
Three phase A.C. generator |
|
Main fuse |
30A |
|
Fuse |
10/10/10/10/10/15A、
10/10/10/10/10/15/20A(ABS) |
|
Headlight |
12V 60/55W (H4) |
|
Turn signal light |
12V 21W |
|
Brake light/Tail light |
LED |
|
Position light |
12V 5W×2 |
|
License plate light |
12V 5W |
|
Combination meter light |
LED |
|
Neutral indicator light |
LED |
|
High beam indicator light |
LED |
|
Turn signal indicator light |
LED |
|
Oil pressure/Coolant temperature indicator light |
LED |
|
FI indicator light |
LED |
|
Immobilizer indicator light |
LED |
|
ABS indicator light |
LED |
|
●CAPACITIES |
|
Fuel tank |
17.5 L |
|
Engine oil |
oil change |
3,200 ml |
|
with filter change |
3,600 ml |
|
overhaul |
3,850 ml |
|
Coolant |
2.58 L |
|
|
|
|
|
